Pen Clip Rotation Stage for AxiDraw

The Pen clip Rotation Stage for AxiDraw normally holds a pen (or other instrument) either vertically or at 45° from vertical. The Pen clip rotation stage is a lightweight adapter allowing you to mount the instrument at arbitrary angles, and fine-tune that angle over a range of 90 degrees with a precision of 1 degree.

This adapter is not normally needed in general writing and drawing usage. However certain precision applications of the AxiDraw – particularly those using the AxiDraw as a general purpose XY motion control stage – may find this to be helpful.

You can attach the rotation stage to the front face of the AxiDraw in two orientations, vertical or at 45° from vertical. These orientations, along with the 90° adjustment range, allow you to either adjust between vertical and horizontal, or between vertical and ±45° from vertical. Two small thumbscrews and an engraved bezel allow you to make adjustments and set the angle.
